Features:
Good compatibility and expansion space, does not account for system memory.
DDR3 memory, 1600 1333 4G 8G are supported.
FM2 FM2+CPU interface, FM2 FM2+CPU interface design for higher compatibility.
All solid state power supply capacitors, 5 phase line design, bring a stable gaming experience, avoid blue screen of crash.
HDMI interface for a more HD video experience, avoiding pixel blurring.
Specification:
Material: PCB
Battery Model: CR2032
Motherboard Chip: Integrated chip, sound card network card(core graphics card) main chipset: for AMD A88 A58 A55 A68 A85 audio chip integrated 6 channel audio chip, network card chip onboard integrated network card
Processor Specifications: Support for AMD A10 A8 A6 A4 Athlon full range of graphics chip for APU core graphics, CPU socket FM2 FM2+
Memory Specification: Memory type DDR3, memory slot 2xDDR3 DIMM, support dual channel DDR3 1333 1600MHz
Expansion Slot: PCI E graphics card slotx1, PCI slotx1, USB2.0 slotx2, SATA interfacex4
I O Interface: USB2.0 interfacex4, HDMI interface, VGA interface, PS 2 mouse, PS 2 keyboard interface, RJ45 network interface, audio interface
Other Parameters: A 4 pin power socket, a 24 pin power interface, five phase power supply mode, other features:
anti thunder, anti static, anti short circuit, anti pulse
Package List:
1 x Motherboard
1 x SATA Cable
1 x Baffle
Note:
The color of the bottom plate of the slot may vary from batch to batch, product is continuously optimized and upgraded, so it will not affect the use of the product.
.
